/*====================================================================* - Copyright (C) 2001 Leptonica. All rights reserved. - - Redistribution and use in source and binary forms, with or without - modification, are permitted provided that the following conditions - are met: - 1. Redistributions of source code must retain the above copyright - notice, this list of conditions and the following disclaimer. - 2. Redistributions in binary form must reproduce the above - copyright notice, this list of conditions and the following - disclaimer in the documentation and/or other materials - provided with the distribution. - - THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS - ``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT - LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR - A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL ANY - CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, - EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, - PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR - PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY - OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING - NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS - SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. *====================================================================*/
Note: The following are highlights of the changes in each version. They are not a complete listing of the modifications.
1.85.0 Oct 16, 2024
* Use wrapper callSystemDebug() instead of system() in programs.
* Fixed Issue #730: artifacts and bad compression with pixWriteJp2k.
Results are now identical with ImageMagick convert (to jp2).
* With PR732, Anton Tykhyy made pix(Read,Write)MemJp2k work with
direct memory access using openjpeg opj_stream functions. This
removes need for temp file on Windows when writing to/from memory.
* Achieve consistency with fclose() in library and lept_fclose()
in progs. Ditto for lept_free, lept_calloc, lept_fopen(), etc.
* Fix generation of bad colormap indices in
jbcorrelation and jbrankhaus
* Fixed coverity scan issues.
* Added findpattern2_reg.c to show generation of sels and their use.
* Added misctest2.c to show crop and clean page functions.
* Added page crop option for removing noise on left and right sides.
* Added page crop option to allow printing to full width of paper.
* Added page crop option to extract page within larger black image.
* Added renderpdf.c to library, to render pdfs as page images with
a specified resolution.
* Modified cleanpdf.c to use l_pdfRenderFiles().
* Issues #750, #752: problems in bmpio.c with taking address of
packed member.
* Source files changed: adaptmap.c affinecompose.c,
bmpio.c, boxbasic.c, colormap.c, compare.c,
dewarp1.c, dnabasic.c, fpix1.c, gifio.c,
gplot.c, grayquant.c, jbclass.c, jp2kheader.c,
jp2kheaderstub.c, jp2kio.c, jpegio.c, libversions.c,
morphseq.c, numabasic.c, pageseg.c partify.c, pdfapp.c,
pdfio2.c, pix2.c, pixabasic.c, pixcomp.c, pixconv.c,
pnmio.c, psio2.c, ptabasic.c,
readfile.c, recogbasic.c, renderpdf.c,
sarray1.c, sel1.c, utils2.c, writefile.c,
allheaders.h, environ.h
* Prog files changed: alltests_reg.c, binmorph3_reg.c,
blend2_reg.c, blend4_reg.c cleanpdf.c, compressedpdf.c, croppdf.c,
findpattern_reg.c, findpattern1_reg.c findpattern2_reg.c,
htmlviewer.c, jbcorrelation.c, jbrankhaus.c,
jp2kio_reg.c, libre_makefigs.c, misctest1.c, misctest2.c,
pdfio2_reg.c, printimage.c, printsplitimage.c,
printtiff.c, psioseg_reg.c, splitpdf.c,
string_reg.c, tiffpdftest.c, xtractprotos.c
1.84.1 Jan 3, 2024
* Remove support for openjpeg versions < 2.1.
* Improve error handling for stringLength() and stringCat(), and
add tests in prog/string_reg.
* Source files changed: blend.c, dnafunc1.c, jp2kio.c, pageseg.c,
partify.c, pix1.c, ptafunc2.c, sarray2.c, utils2.c
* Prog files changed: boxa3_reg.c, string_reg.c, writetext_reg.c,
deskew_it.c
1.84.0 Dec 23, 2023
* Add getPdfPageCount() to find the number of pages in a pdf file.
* Add getPdfPageSizes() and getPdfMediaBoxSizes() to find the
information necessary to render images properly. Modify cleanpdf.c
and concatpdf.c to use this information.
* Add prog/splitpdf.c to split a pdf file into nearly equal page sets.
* Add ability to read and write rgba in bmp format, and
test in ioformats_reg.
* Add regression test prog/partition_reg.c
* Change the autotools library name from liblept to libleptonica,
to be consistent with the cmake library name. (Apologies to Jeff!)
* Add tests for 24 bit pix reading and writing in bmp and png in
ioformats_reg. Test new pixDisplayDiff() for visualizing diffs.
* Allow prog/concatpdf to output pdf with tiffg4 encoding and with
mixed tiffg4 and DCT encoding depending on image color content.
* Rename prog/concatpdf --> prog/compresspdf
* Put image processing and generation of output pdf from compresspdf
and cleanpdf into functions in new files: pdfapp.c, pdfappstub.c.
* Add versatile function for cropping an image and filling to
page size, along with prog/croppdf to do this on pdf file.
1.83.0 Dec 20, 2022
* Simplify setting the title of pdf files.
* Catch tiff failure to open stream in fopenTiffMemStream()
* Check for POSIX functions fstatat() and dirfd() before use.
* In prog/cleanpdf: do not allow threshold to exceed 190. Make all
parameters required; do not use default values for invalid parameters.
* In prog/concatpdf: add input param for title; add jpeg quality factor
* Fix flaky hash_reg test on i686: sets generated from SelectRange()
can depend slightly on platform.
* Convenience function for adding multiple black and white borders.
* Fix oss-fuzz issue 42202: underined shift in l_convertCharstrToInt().
* Fix oss-fuzz issue 43841: made pixCountPixels() more efficient.
* Fix oss-fuzz issue 44008: pixCountArbInRect() used wrong depth.
* Always return tiff resolution of 0 (unknown) if not set.
* Simplify operations on pix memory to help avoid mem leaks
* Make bmp non-support of 32-bit bmp (rgba) files explicit.
* Improve tiff read resolution conversion by rounding.
* Use stdatomic.h to make cloning string safe.
Remove all *GetRefcount() and *ChangeRefcount() accessors.
* Replace procName and mainName strings by __func__.
* Remove information about fields in many structs from the public
interface allheaders.h, instead putting them in internal files
pix_internal.h, array_internal.h and ccbord_internal.h.
* Increase the .so number from 5.4.0 to 6.0.0.
* Rename the autotools generated libraries from liblept to libleptonica
* Fix potential memory leaks from recogAverageSamples() and
recogDebugAverages() by not destroying a recog.
1.82.0 Sept 22, 2021
* Fix issue-585: reading tiff rgb with tiffbpl = 1.5 * packedbpl.
* Fix issue-586: failure to properly wrap tiff-g4 in pdf without
transcoding. The fix is to do transcoding for tiff-g4, as was
done before April 2021.
1.81.1 June 11, 2021
* Added choice of codec (JP2 or J2K) when writing jp2k files.
* Fix use of hashmap with key based on dna.
1.81.0 June 6, 2021
* Fixed problems with tiff pdf wrapping photometry.
* Fixed scaling issues in prog/cleanpdf for printing.
* New progs: tiffpdftest, hashtest
* Fixed uninitialized data error in pixAddBorderGeneral() and
pixRemoveBorderGeneral()
* Rewrote Numa functions that discretize into bins. Have
binning by both sorting and histogram.
* Rewrote and simplified pixGetRankColorArray() and pixGetBinnedColor().
* Added tests to prog/rankbin_reg.c.
* Simplified fpixCopy() and dpixCopy(), and functions that use them.
* Check input for bilateral transforms.
* Add function for splitting a file evenly by lines.
* Check input for getFilenamesInDirectory()
* Many new fuzzers.
* Use size_t for all size inputs to ascii85 encoding/decoding
* New regression tests: encoding_reg.c, binmorph6_reg.c,
flipdetect_reg.c
* Reworked concatpdf for generality, using the Poppler package.
* Removed dwa flipdetection from the library. All the dwa code
is now in flipdetectdwa.c.notused. Likewise prog/flipselgen.c
is retained for completeness, renamed flipselgen.c.notused,
and is not compiled.
* Added hashmap utility (hashmap.c, hashmap.h).
* Removed functions using dnahash on strings, pts and doubles.
* Improved the speed of hashing for strings and doubles.
* Added function for tiling images in pairs for comparison.
* Added null terminations to serialized strings written to memory,
preventing buffer overrun by strlen() [fixed by Stefan Weil].
* No longer use "NoInit" versions of pix creation in leptonica.
because they risk reading uninitialized data. These functions
remain in the library because they are in use in applications.
* Add two composite binarization functions, from prog/binarize_set.
* Giulio Lunati fixed pnm reading to work with stdin input.
* Removed several of the boxa compare and modify functions.
* Implemented reading jpeg200 data encded in j2k "codestream" format.
Can now read data in both jp2 and j2k.
1.80.0 28 July 2020
* Improve bmp handling of 1 bpp images and sanity checking of params.
* Add function to display all rgb gamut colors
* in Makefile.am, use option serial-tests to avoid races in testing
* Make m4 subdirectory and add ax_split_version.m4 there
* Simple function for hue-invariant mapping (pixMapWithInvariantHue)
* Fixed bug in limit of ptra size when used for sorting by bins.
* Use hashmap to count pixel colors in RGB(A) images.
* Convert hashtest program to regression test hash_reg.
* Convert croptest program to regression test crop_reg.
* New color segmentation by region growing (colorfill.c)
* New regression tests: colorfill_reg, circle_reg, ccbord_reg.
* Set maxima for all allocations for common leptonica data structures.
* Don't fail when downscaling 2, 4, 8, and 32 bpp images, even
to one pixel, invoking pixScaleSmooth().
* New functions that select 1 bpp components based on their area.
* Incremental addition to sorted array of numbers.
* new prog/fuzzing directory for oss-fuzz based fuzzing programs
* use of pixcmapIsValid() with extra argument to determine validity
with the pix it is attached to.
* Use lept_stderr() in all programs in the prog directory.
* New program rasteroptest() for thorough testing of rasterop functions.
* Removed the pixSaveTiled*() functions
* Stubbed pixDisplayWrite(). Last used in tesseract 3.04.01 (2/2016).
1.79.0 1 Jan 2020
* Clean up auto-generation of files; removed 'register'
* Some fixes for issues identified by fuzzer
* New source files: checkerboard.c
* New programs: replacebytes.c, webpanimio_reg.c, partifytest.c,
rectangle_reg.c, lowsat_reg.c, rotate_it.c, scale_it.c, dewarp_it.c,
pdfio1_reg.c, pdfio2_reg.c, checkerboard_reg.c, underlinetest.c.
* Convert to standard reg test: heap_reg.c, pixa1_reg.c, smallpix_reg.c
* Improve data checking when reading image file headers
(pnm, png, jpeg, tiff)
* Fix some bugs in pnm reading
* Fix inconsistencies with the encoding type flags in pdf writing
* Allow tiff to write images with colormaps
* Fix errors in PS code; made some functions static
* Add code for animated webp (requires webp mux and demux libraries)
* Add "partify" application for separating parts in a musical score
* Enable tif read/write of gray+alpha and rgba; filter out tiff
pixels that are not uint and compression by tile
* Apply consistent formatting of static const variables
* Add programs for scaling, rotation and deskew, named dewkew_it,
rotate_it and scale_it, for useful operations on arbitrary images.
* Convert pdfiotest program to two regression tests: pdfio1_reg
and pdfio2_reg.
* Remove all use of strncat; use stringCat().
* New functions from removing outliers in sequences of boxes.
* Generalize pixAverageInRect(): mask, region and range filters,
and subsampling. New pixAverageInRectRGB().
* Fix int overflow bug in pixMedianCut(); required new heap accessor.
* New pixMultiplyGray() allows pix to be multiplied by an array (or
another pix)
* Better routines for counting color.
* Lossless conversion for RGB to cmap with not more than 256 colors.
* New histo based global thresholding: pixThresholdByHisto().
* Allow most reg tests to run even if external libraries are not
available.
* New one-line gplot functions that return a pix.
* New application to find where corners meet in a checkerboard.
* Add utility functions for painting through mask in cmap pix,
creating a hit-miss sela from a color pix, equality of two pta.
* Proper handling of 1 bpp colormap tiffs: remove when reading,
preserve when writing.
* Deprecate three pixSaveTile*() functions; removed all calls to
these from the library and progs.
* Include auto_config.h explicitly in all src and prog files.
* Improve input data checking for bmp files.
* Added pixAutoPhotoinvert() for tesseract, to automatically photo-
invert text regions where the background is black and text is white.
1.78.0 21 Mar 19
* Various improvements in handling boxa sequences and transforms.
* New regression tests: boxa4_reg, string_reg
* New function for copying a pix, filtered by a boxa.
* Modify histogram method for image comparison.
* More careful attention to invalid boxes in box geometry functions.
* Better string and array functions for search and replace.
* Convenience functions for generating simple masks.
* Allow pdf writing of jp2k images, in full generality.
* Allow writing compressed ps images for printing.
* Modified enum comments to include a suggested enum name.
* New program: imagetops
1.77.0 14 Dec 18
Here is the current status of CVE issues with leptonica; see
https://security-tracker.debian.org/tracker/source-package/leptonlib
* CVE-2018-7442: potential injection attack because '/' is allowed
in gplot rootdir.
Functions using this command have been disabled by default in the
distribution, starting with 1.76.0. As for the specific issue, it
is impossible to specify a general path without using the standard
directory subdivider '/'.
* CVE-2018-7186: number of characters not limited in fscanf or sscanf,
allowing possible attack with buffer overflow.
This has been fixed in 1.75.3.
* CVE-2018-3836: command injection vulnerability in gplotMakeOutput().
This has been fixed in 1.75.3, using stringCheckForChars() to block
rootnames containing any of: ;&|>"?*$()/<
* CVE-2017-18196: duplicated path components.
This was fixed in 1.75.3.
* CVE-2018-7441: hardcoded /tmp pathnames.
These are all wrapped in special debug functions that are not
enabled by default in the distribution, starting with 1.76.0.
* CVE-2018-7247: input 'rootname' can overflow a buffer.
This was fixed in 1.76.0, using snprintf().
* CVE-2018-7440: command injection in gplotMakeOutput using $(command).
Fixed in 1.75.3, which blocks '$' as well as 11 other characters.
Wrapped the few 'system' calls in an extra layer of debug code.
More coverity scan fixes; defects are about 1 per 10,000 source lines.
New regression tests: numa1_reg, numa2_reg, lowaccess_reg,
pixmem_reg.
New non-regression test programs: histoduptest
Juergen Buchmueller is working on Lua bindings. He typedef'd l_ok
and used it in 1100 functions that return a success/failure status.
He also helped clean up remaining issues in the doxygen-generated
documentation.
Using a packed struct for bmp headers to avoid crash on
some big-endians.
Fixed a bug in the prototype parser for xtractprotos that was
surfaced by a typedef declaration for the bmp headers.
Cleaned up IOS guards to avoid compiling a system(3) call on IOS.
Renamed autobuild --> autogen.sh
Added some basic pixa functions for rotation and translation.
Added an iterative method to find rectangular coverings for
arbitrary connected components.
Converted two tests to reg tests running in alltests_reg:
ptra1_reg, ptra2_reg
Enabled read/write for standard jpeg compressed tiff images.
Enabled reading for the old (deprecated) jpeg-encoded tiffs.
Fix range selectors for pixa, pixaa, boxa, boxaa, pta:
Now, last = -1 goes to the end.
When reading tiff --> pix, insert IMAGEDESCRIPTION into text field.
Converted iotest to reg test iomisc_reg; added to alltests_reg
Converted rasterop_reg into a standard regression test; added
to alltests_reg.
Converted boxa2_reg and fhmtauto_reg into standard regression tests;
added to alltests_reg.
Split boxa sequence functions out of boxfunc4.c, into a new boxfunc5.c.
Simplified bmp header and made reading more clearly endian
agnostic (Juergen Buchmueller)
New boxa3_reg regression test. This tests sequences of boxes
by two new boxfunctions in boxfunc5.c.
New bootnumgen4.c for more digit templates.
Rename prog/recog_bootnum.c --> prog/recog_bootname1.c
New in prog: recog_bootnum2.c, recog_bootnum3.c, recogtest7.c
Fixed uninitialized data in pixCentroid() on 1 bpp pix.
New reg test: bytea_reg.c. (removed byteatest.c)
Fixed bug in non-transcoding pdf generation from 1 bpp png.
Added LGTM to static analyzers that run over the library.
1.76.0 1 May 18
Modify infrastructure to fix outstanding security issues. By default,
you can no longer create temp directories and temp files whose
names are known to the compiler. Also, prevent "system" calls,
which were used for image display and gnuplot.
Replaced remaining sprintf() with snprintf() in prog tests.
Added non-transcoding functions for generating pdf from jpeg pixacomp
Add control of jpeg quality from pixWriteMem() and pixWriteStream()
Fixed getFilenamesInDirectory() to properly identify directories
Prevent size overflow in calloc for kernel; cleaned it up fpix and dpix
bmp reading now accepts negative height
Simplified splitimage2pdf; it no longer uses ps2pdf
Remove name-mangling WRITE_AS_NAMED compile option.
Removed 2 deprecated write functions.
Added these regression tests:
locminmax_reg, speckle_reg, watershed_reg,
1.75.3 15 Feb 18
Fixed some coverity scan issues.
Autotools fix to check for png if enabling gnuplot (James Le Cuirot).
1.75.2 11 Feb 18
Converted several progs to standard regression tests.
Added these tests to the alltests_reg suite:
adaptnorm_reg, binmorph1_reg, binmorph3_reg, equal_reg,
extrema_reg, grayfill_reg, falsecolor_reg, grayquant_reg.
Autotools fix for restricting giflib to 5.1+, and allowing
openjpeg 2.3 (James Le Cuirot).
1.75.1 31 Jan 18
Simpler and more accurate function for finding word masks from
text image; better debugging and more thorough testing.
Added to regression test set: prog/italic_reg
Fix for potential injection attack using gplot rootdir.
Bug fix for bmp reading to set opacity.
1.75.0 24 Jan 18
This is a new version, for major Ubuntu release 18.04.
$TMPDIR path rewriting turned off on Unix; only used for Windows.
Added pix conversion to depth 2 and 4. We now have general
converters to 1, 2, 4, 8, 16 and 32 bpp.
Modified giflib to use read/write from/to memory; no temp files;
no longer support versions before 5.1.
Move most low-level code from separate files to their callers;
about 30 of them became static.
Improved table detection on scanned page images (tests: pageseg_reg.c)
Added support for write/compare regression tests for files.
Modified printimage for more flexibility.
Enable lookup by key on comma-separated key/value text file.
Update README.html for building with Visual Studio.
Improved functions for getting pixel averages in RGB images
Simplified and speedup of unsharp masking.
New function for detecting and correcting text orientation.
Remove slow sharpening operation when not appropriate during scaling.
Better handling of gplots with 0 or 1 data point.
Coverity scan fixes.
Modified jpeg2000 header to use openjpeg 2.3.
Improved depth accessors for pixa and pixaa; added size accessors
for pixa and pixaa.
Bug fix in webp interface on read error.
New function that finds the closest boxes in a boxa to any particular
box, in each of 4 directions.
New regression tests in automated sequence: blend5_reg, quadtree_reg,
wordboxes_reg.
New program: textorient
Removed programs: snapcolortest
1.74.4 11 Jun 17
Converted two progs to reg tests
New version because 1.74.3 had some spurious files (xtractprotos,
endianness.h)
1.74.3 9 Jun 17
Coverity scan fixes.
Several fixes for running on Windows, including subtle one with tiff
encoding depending on pad bits.
Utility and test if a page image likely has a table.
Remove use of pixCreateTemplateNoInit() where it may cause problems.
Make release 'configure-make ready'
1.74.2 19 May 17
Many simplifications and improvements to recognizer.
Cleanup of doxygen comments
Encoded pdf title in escape 4-byte hex (for safety)
Fixed several hundered coverity scan possible leaks
Added about 20 regression tests to the automated set.
Improved vertical alignment of dewarp.
Implemented preliminary method for correcting dewarp foreshortening
due to page curvature.
Improved multipage tiff reading and writing.
Added a new version of textline finding.
Fixed bug in fast 2D sharpening code (used in some scaling ops)
BMP i/o rewritten to implement memory version directly.
PNG i/o functions added for encoding and decoding directly to memory.
Method for finding light color regions on scanned page images.
1.74.1 3 Jan 17
Configuration changes to support the patch number in the
version (major.minor.patch).
Removed all remaining pixDisplayWrite() calls in prog/.
Cleaned up and/or promoted about 15 programs to full regression
tests. There are now 95 tests in the regression set.
Over half the initial coverity scan warnings have been removed.
1.74.0 10 Dec 16
Leptonica development was moved to github. The master is at:
github.com/danbloomberg/leptonica
Egor Pugin is the maintainer of the site.
A very large number of changes have been made. Some of them follow;
details can be found in the git commit messages.
Static makefiles modified to work with gnu*9 and c*9.
Modify SET macros to work on windows.
New modes for RGB --> gray conversion.
New functions added for displaying a pix from a pixa.
Split out sort/hash/set/map functions for dna, sarray and pta.
More robust horizontal deskew on multi-column page images.
Improve webpio_reg test.
Remove X11 display for gplot; it is no longer supported.
Remove most sleep calls, which were put in for gplot; no longer needed.
Removed use of gthumb in library.
Removed use of pixDisplayWrite() in the library; still in some progs.
Improved test for endianness in makefile.static; no longer requires
any local files or building and running a program.
Modified all files for doxygen output (spearheaded by
Juergen Buchmueller)
Improved plotting of the boxes in a boxa.
Replaced the slow point hash function with a simple fast one.
Added pam (4 component) format writing to pnmio.c (Juergen Buchmueller)
Improved rendering of pixa in side/by/sides.
Better utilities for pixa and pixacomp.
Add read/write serialization functions from/to memory for all
the major data structures that do not already have them.
More serialized boot recognizers stored as self-generating code.
Cleaned up generating an adapted recognizer from the boot recognizer.
Simplified temp file naming; removed most instances of named
temp files from non-debug code; use tmpfile() and a wrapper
l_makeTempFilename().
Simplify and streamline multipage tiff reading (Jeff Breidenbach).
Improvement of Otsu thresholding.
Recognize outstanding contributors to leptonica over the years.
New gif mem read/write interface that avoids writing a temp file,
contributed by Tobias Peirick.
Use double arrays (dna) instead of float (numa) for set ops.
Enrolled in coverity scan to find potential bugs (Stefan Weil
managed it). Fixed about 200 of them, mostly potential memory
leaks from early function exit.
Cleanup of gray quantization functions and tests.
Refactored connectivity-conserving operations, to make them more useful.
Provided methods for measuring and regularizing the width of strokes.
Removed viewfiles.c from library; code is now in prog htmlviewer.c.
Better debugging in page segmentation (pageseg.c)
Deprecated the pixDisplayWrite*() debugging methods.
Added about 15 regression tests to the framework in alltests_reg.c
Final mods for compatibility with tesseract 4.00.
1.73 25 Jan 16
All lept_* functions have been rewritten to avoid path rewrites for
output to temp files, which were introduced in 1.72.
Now, (1) files are written to the directory specified and (2) we
are careful to write to subdirectories of /tmp/lept/ for all test
programs, starting with the reg tests and prog/dewarp* and
prog/recog*. This also required re-writing stringcode.c and
stringtemplate1.txt to write temp files to subdirectories.
Goal is to write to the specified path while not spamming the
/tmp and /tmp/lept directories. This is particularly important
on windows because files in the directory are not cleared
on reboot.
Naming changes (to avoid collisions):
#defines MALLOC --> LEPT_MALLOC, CALLOC --> LEPT_CALLOC, etc.
ByteBuffer --> L_ByteBuffer
Added grayscale histogram functions that can be used to compare images.
Added functions to determine if an image region has horizontal
text lines.
Added functions to compare photo regions of images to determine
if they're essentially the same.
Added red-black tree utility functions to implement maps and sets.
The keys for maps and sets can be 64-bit entities (signed and
unsigned integers and doubles).
Implemented hashsets and hashmaps, using 64 bit keys.
Replaced the numaHash by l_dnaHash; removed numa2d
Improved security of tiff and gif reading, to prevent memory corruption
when reading bad data.
Removed src files: bootnumgen.c
Added src files: rbtree.c, rbtree.h, map.c, bootnumgen1.c, bootnumgen2.c
Added prog files: rbtreetest.c, maptest.c, settest.c, hashtest.c,
recog_bootnum.c, percolatetest.c
Added files for building using cmake (Egor Pugin)
1.72 5 Apr 15
Better handling of 1 bpp colormap read/write with png so that
they are losseless. The colormap is always removed on read and
the conversion is to the simplest non-cmapped pix that can fully
represent the input -- both with and without alpha.
Fixed overflow bug in pixCorrelationBinary().
Fixed orientation flags and handling of 16 bit RGB in tiff.
Also new wrappers to TIFFClientOpen(), so we no longer go through
the file descriptor for memory operations.
Improvements in the dewarp functions.
New box sequence smoothings.
New antialiased painting through mask; previously it was only
implemented for connected components in a mask.
Better error handling and debug output with jpeg2000 read/write.
Implemented base64 encoding. This allows binary data to be represented
as a C string that can be compiled. Used this in bmf utility.
Implemented automatic code generation for deserialization from
compiled strings (stringcode.*)
Regression tests write to leptonica subdir of in windows; in
unix it is optional. This avoids spamming the directory.
Added new colorspace conversions (XYZ, LAB).
New source files: encoding.c, bmfdata.h, stringcode.c, stringcode.h,
bootnumgen.c.
Removed source files: convolvelow.c, graymorphlow.c
New programs: genfonts_reg, colorize_reg, texturefill_reg,
autogentest1, autogentest2.
alltests_reg now has 66 tests.
1.71 18 Jun 14
This version supports tesseract 3.04. In particular, 3.04
has automatic conversion of a set of scanned images, either in a
directory or coming directly from a scanner, into pdf with injected
text. This is something we've wanted to do for several years!
Improved jp2k header reading, including resolution.
Removed src files: rotateorthlow.c, pdfio.c, pdfiostub.c
Renamed jp2kio.c, jp2kiostub.c ==> jp2kheader.c, jp2kheaderstub.c.
These header reading functions parse the jp2k files, and
don't require a jpeg2000 library.
New jp2kio.c, jp2kiostub.c, that uses openjpeg-2.X to read
and write jp2k. We now support I/O from these formats:
png, tiff, jpeg, bmp, pnm, webp, gif and jp2k
as well as writing to PostScript and pdf.
New pdfio1.c, pdfio1stub.c, pdfio2.c pdfio2stub.c, where we've
split functions into high and low level.
Fixed memory bug in bilateral.c
Improved reading/write of binary data from file. For example,
l_binaryReadStream() can now be used to capture data piped
in via stdin.
Font directory now arg passed in everywhere (not hardcoded)
Don't write temporary files to /tmp; only to a small number of
subdirectories, to avoid spamming the /tmp directory. E.g.,
for regression tests, the current output is now to /tmp/regout/.
For jpeg reading modify pixReadJpeg() to take as a hint
a bit flag that allows extraction of only the luminance channel.
Allow wrapping of pdf objects from png images without transcoding
(thanks to Jeff Breidenbach)
Better support for alpha on read/write with png, including
1 bpp with colormap, alpha (supported in png with transparency array)
1.70 3 Feb 14 (distribution to debian; ubuntu 14-04; 4.1.0)
New bilateral filtering.
New simple character recognition utility.
Improved dewarping functionality, in model building and rendering.
More flexible use of ref models.
Better and more consistent handling of alpha layer in RGBA, though
use of the spp field. Ability to handle more png files with alpha,
including palette with alpha.
New fast converters from jpeg and jpeg2000 to pdf, without transcoding.
Made bmp reader (and pix reading in general) more robust; avoid
size overflow errors.
New text labelling operations; depth conversion of a set of images
New license (essentially BSD 2-clause), to specify conditions
for both source and binary distribution.
Improved auto make: make all progs, install just 11, test 61.
New src files: bilateral.{c,h}, dewarp1.c, dewarp2.c,
dewarp3.c, dewarp4.c, jp2kio.c, jp2kiostub.c,
pixlabel.c, recogbasic.c, recogdid.c, recogident.c,
recogtrain.c, recog.h
New prog files: adaptmap_dark.c, alphaxform_ret.c,
bilateral_reg.c, binarize_reg.c, binarize_set.c,
blackwhite_reg.c, blend1_reg.c, blend3_reg.c, blend4_reg.c,
boxa1_reg.c, colorcontent_reg.c, coloring_reg.c,
colorspace_reg.c, compare_reg.c, converttopdf.c,
croptest.c, dewarprules.c, dewarptest1.c, dewarptest2.c,
dewarptest3.c, dewarptest4.c, displayboxa.c, displaypix.c,
displaypixa.c, findcorners_reg.c, fpix1_reg.c,
fpix2_reg.c, fpixcontours.c, insert_reg.c, italictest.c,
jpegio_reg.c, label_reg.c, multitype_reg.c, nearline_reg.c,
newspaper_reg.c, numa1_reg.c, numa2_reg.c, recogsort.c,
recogtest1.c, shear1_reg.c, webpio_reg.c, wordboxes_reg.c
Removed src files: arithlow.c, binexpandlow.c, binreducelow.c,
dewarp.c
Removed prog files: blend_reg.c, blendtest1.c,
dewarptest.c, fpix_reg.c, inserttest.c, numa_reg.c, rotatetest2.c
shear_reg, xvdisp.c
1.69 16 Jan 12 (distribution to debian; ubuntu 12-04; 3.0.0)
Fixed bug in pdf generation for large files, using a new
double array (dnabasic.c). Added several new modes for pdf
generation from sets of images.
Dewarp based on image content now aligns to left and right margins;
works at book level; is more robust to bad disparity models;
version 2 serialization.
Fixed regutils to return the actual number of errors.
Improved sorting efficiency of numas in cases where binning,
which is order N, makes sense.
Fixed fpix serialization (now version 2).
New version (5) of xtractprotos, allows putting prototypes in-line in
allheaders.h. Having them separately in leptprotos.h still an option
New copyright (BSD, 2 clause) on src files.
Removed all trailing whitespace in src files.
New src files: boxfunc4.c coloring.c, dnabasic.c
New prog files: dna_reg.c, alphaops_reg.c
Removed prog file: alphaclean_reg.c
1.68 10 Mar 11
Fixed windows issues with passing pointers across C-runtime boundaries
when using dlls, by providing special functions (e.g., lept_fopen()).
Proper version numbers are now set with automake.
New utility (quadtree.c) for generating quadtree statistics.
New utility (in colorspace.c) for conversions to and from YUV.
Refactored functions for assembling image data for generating
either PS or PDF images using g4, jpeg or flate encoding.
Better tempfile names, using current time in microseconds.
Functions for getting resolution from jpeg and png files.
Use size_t throughout for reading and writing binary data.
Deprecate arrayRead*() and arrayWrite() functions; replace in
the library with l_binaryRead*() and l_binaryWrite().
Better handling of colormap images for in-place rasterop and shear.
New utility (bytearray.c) for parsing and handling binary data;
used for generating PDF files.
New utility (pdfio.c) for generating PDF files.
Refactored regutils functions to make them simpler to use.
Top-level deskew now works on any image.
Added functions in utils.c for cross-platform development, mostly
for functions that make and remove directories, copy, move
and delete files, etc. It should now be straightforward to write
programs that will compile and run on windows.
Reg tests have better printout; all give timings.
New utility program: convertfilestopdf
1.67 9 Nov 10
Autoconf: now built with James Cuirot's config files that
build the library and all 200 progs.
New sudoku solver. Just a game, but there are interesting aspects.
Modified parseprotos.c to reject a type of "extern" decl.
Add faster implementation for very small gray morphology
operations (3x1, 1x3, 3x3).
Eliminate warnings on recent gcc if you don't check return values
from fread, fscanf, fgets, system, etc.
Convolution: new functions for windowed variance and stdev; allow
non-square kernel for windowed mean square.
Put stdio.h and stdlib.h in alltypes.h, so they're not required
in any .c files.
Replace numaConvolve(), which is just a windowed mean, by
windowed statistics functions (mean, mean square, variance).
Generalize pixExtractOnLine() for arbitrary lines.
Add pix interface to webp (webpio.c, webpiostub.c). This is a
new open source codec, based on the video codec vpx (webm).
Serialization of FPix and DPix
Interconversion between FPix and DPix
Integer scaling of FPix and DPix; includes the last row and column.
New convertfiles.c: depth conversion on files in a directory.
Testing programs in prog:
convolve_reg.c, numa_reg.c: expanded test set
projection_reg.c (tests pixRowStats(), pixColumnStats())
dewarptest.c: output ps and pdf files
writemtiff.c: simple driver to write images to a single file
1.66 3 Aug 10
More tweaks for including (or not) bounding box hints for
PS wrapping. Default is to write b.b., but not in functions
that wrap images as full pages (psio1.c, psio2.c)
pix4.c split in two files, and added function to identify c.c.
that are sufficiently similar in shape to rectangles (pix5.c)
Modify 2 and 4 bit setters to clip the input value so that it can
only affect the pixel requested (arrayaccess.c, arrayaccess,h)
New pseudorandom sequence functions (numafunc1.c)
Dewarping camera-based images using textlines (dewarp.c, prog/dewarp*)
Geometrical function for aggregating overlapping bounding boxes.
Programs to generate figures for book chapter "Document Image
Applications" in "Mathematical Morphology: theory and applications"
(see: http:/www.leptonica.org/najman-talbot-book-chapter.html)
(prog/livre*.c)
Functions that do affine and other operations in images with
alpha blending at edges: pix*WithAlpha(). Also do this
with a gamma/inverse-gamma wrapper to further reduce edge aliasing.
(rotate.c, scale.c, projective.c, affine.c, bilinear.c,
prog/alphaxform_reg.c)
Improved color segmentation (fixed bugs; made faster)
Higher order least square fits: quadratic, cubic, quartic. (pts.c)
Various mods for otsu binarization and the *SplitDistribution*()
functions (numafunc2.c, prog/otsutest2.c)
Control sampling in convolution output (convolve.c, prog/fpix_reg.c)
Morphological operations on numas (numafunc1.c, numafunc2.c,
prog/numa_reg.c)
Pix serialization wrapped so we can use pixRead(), etc on these
files (spixio.c, readfile.c, writefile.c)
Gif read/write to memory fixed (and cheated -- using files) (gifio.c)
New fpix and dpix accessors; contour rendering on fpix (fpix1.c, fpix2.c)
Various functions for linearly mapping colors and displaying arrays
of colors (pix4.c, blend.c, prog/rankhisto_reg.c)
Functions for getting approximate ranges of colors and color
components in an image (pix4.c, colormap.c)
Cleaned up windows platform and compiler defines and macros.
1.65 5 Apr 10
Added regression test utility functions for standardizing and
automating construction and running of regression tests. Makes the
golden files when the 2nd arg to the reg test is 'generate'.
(regutils.{c,h})
Converted 22 reg tests in prog to use this; invoked with alltests_reg.
Goal is to put all prog/*_reg.c into this format and put a set
of golden files on the web.
Small fixes in gifio for handling streams properly.
New functions for shifting colors, hue invariant transforms, etc
(blend.c)
prog/dwamorph*.c: rename *1_reg.c to dwalineargen.c; others
converted to standard reg tests.
New rgb convolution functions.
For PS output, write all images with a bounding box hint and with
page numbers, which works for both embedded (e.g., in tex) and
full page generated PS. Once converted to pdf, this is fine
in all situation.
New functions for initialization and random insertion with pixcomp.
For color quantization, make the lightest color white if sufficiently
close; ditto for black (colorquant1.c, colorquant2.c).
Rank binning of 8 bpp and rgb images (numafunc2.c, pix4.c)
A function to rank colors by the intensity of the minimum comp (pix4.c)
New pixRotateBinaryNice(), rotates 1 bpp pix in such a way that
the shear lines aren't visible. (rotate.c)
New pixSaveTiledWithText(), a convenience function to append text
to images that are being tiled. (writefile.c)
Stereoscopic warping functions and stereo pair functions (warper.c)
Linear interpolated shear -- better than rasterop shear (shear.c)
Option to use higher quality chroma (U,V) sampling in jpeg (jpegio.c)
Rename Bmf --> L_Bmf.
New tests in prog:
alltests_reg.c alphaclean_reg.c, psio_reg.c, rankbin_reg.c,
rankhisto_reg.c, warpertest.c
1.64 3 Jan 10
Easy setup for standard byte processing on 8 bpp pix (pix2.c)
Evaluation of difference between similar images; test for
similar images and (compare.c)
Subpixel scaling, with color input and separate scale factors (pixconv.c)
Fix tiff header reader to get correct format (tiffio.c)
Enable pixDisplay() to work with i_view (windows) and with
xzgv and xli as well as xv; allow application to choose
which to use (writefile.c).
Use a mask to specify regions that are changed by a morphological
operation (morphapp.c).
Improve the default sharpening for scaling (scale.c)
Function to test for equivalence of file data (utils.c)
Select and read image files with embedded index (readfile.c)
Fix box size calculation in pixEmbedForRotation(); solution
provided by Brent Sundheimer.
New pixDisplayMultiple(), instead of calling gthumb directly; this
is now set up to use i_view for windows.
Changed criteria for determining if an image is color (colorcontent.c,
colorquant{1,2}.c.
Optional mode where the filename extension is automatically written
to output image files; particularly useful for windows.
Initialize boxa and pixa as full, with minimal placeholders.
Get rank valued numbers and boxes in numa and boxa.
Cute implementation for finding largest solid rectangle (maze.c)
New median cut quantization for mixed (color/gray) images (colorquant2.c)
Many changes to allow the library and applications be built easily
in windows. There is now a thorough windows readme, written by Tom
Powers, for doing this. The windows build information and
project files are now in a new vs2008 directory.
1.63 8 Nov 09
Added pixScaleToGrayFast(), a faster version with very similar quality.
Fixed scaleGrayLILow() to handle edge pixels more accurately
Text processing:
new text application (finditalic.c, prog/finditalic.c) for locating
words in italic type style.
Easier to add text to a pix using the bitmap font stored in
the font directory; see, e.g., prog/writetxt_reg.c.
Blending of 2 images with an alpha channel: pixBlendWithGrayMask()
Fixed bug in color segmentation; it now (again) works properly.
New utility (pixcomp.c) for handling compressed pix arrays in
memory; new PixComp and PixaComp structs.
Fast serialization of pix without compressing (pixSerializeToMemory
and pixDeserializeFromMemory); required serialized colormaps
FileI/O: new functions for reading file headers.
PostScript generation modernized; split psio.c into psio1.c
and psio2.c; added level 3 (flate) encoding.
new functions for reading and writing multipage tiffs, for
arbitrary input images. For writing, compression is lossless
(either g4 or zip)
update all I/O stub files
Miscellaneous: new pixaAddBorderGeneral(); new functions in pix3.c
for counting fg pixels and summing 8 bpp pixels by column and row;
new numaUniformSampling() for resampling with interpolation;
subpixel scaling.
New or improved regression tests in prog:
extrema_reg, pixalloc_reg, blend2_reg, rotateorth_reg,
ioformats_reg, colorseg_reg, pixcomp_reg, pixserial_reg,
writetext_reg, psioseg_reg, subpixel_reg.
Interface changes:
findFileFormat() and findFileFormatBuffer(): now returns format
using input ptr. The function return value is 0 if OK; 1 on error
rename: pixThresholdPixels() --> pixThresholdPixelSum()
1.62 26 Jul 09
Expanded composite Dwa implementation as a sequence of operations,
so that it now works beyond a size of 63. It's typically about 2x
faster than the composite rasterop implementation (with help
from Ankur Jain). Also use data transfer instead of data copy
whenever possible. Thorough tests with binmorph4_reg and binmorph5_reg.
New functions in colorseg.c for masking and histogramming in HSV
color space.
Treat string constants rigorously as const char*, initializing
to char[] if to be used as non-const, or in some cases casting
to char*. This avoids compiler warnings.
Improved color quantization using existing colormap for octcubes
and a new version for grayscale. This will rigorously map most
black and most white octcubes (rsp) to black and white
if they exist in the colormap.
Fast quantization to an existing colormap for color and grayscale.
Fixed some bugs; e.g., in pixAffineSampled() for 1 bpp with
L_BRING_IN_BLACK; reading and writing pnm for 2 and 4 bpp.
In pngio.c, enable compile time control over these settings:
converting 16 bpp --> 8 bpp on read
removing alpha channel on read
setting zlib compression on write
For general scaling, allow sharpening to be optional, and provided
faster sharpening operations.
Improve support for 16 bpp grayscale.
For scaleToGray* functions, reduce the width truncation.
In psio.c, new functions for converting segmented page images
(text and image) into level 2 PostScript.
Removed all implicit casting to const char*.
New custom pix memory allocator, designed for large pix whose
memory needs to be reused many times.
In xtractprotos, we now allow prepending an arbitrary string to
each prototype.
In environ.h, additions for MSVC to work with VC++6, including
prototpye strings for dll import and export (thanks to Ray Smith).
In colorseg.c, new functions for building HSV histograms, finding
peaks, and generating masks based on the peaks.
New or improved regression tests:
pixalloc_reg, binmorph4_reg, binmorph5_reg, conversion_reg,
scale_reg, cmapquant_reg,
1.61 26 Apr 09
New histo-based grayscale quantization: pixGrayQuantizeFromHisto(),
that is used in new pixQuanitzeIfFewColorsMixed().
Made final fix in pixBlockconv(). No underflows; no more overflows!
More efficient rgb write with pnm.
Add proto to jpegiostub.c, allowing proper use of the stubber.
Fix several filter functions to use proper test on filter size; viz.,
pixMinMaxTiles(), several functions in convolve.c.
Redo shear implementation to handle arbitrary angles, to handle
colormapped images, and to avoid the singularity at pi/2.
Removed both static vars from pixSaveTiled().
Generalized pixRotate() to handle colormapped images, and to use
pixRotateBySampling() in place of the removed pixRotateEuclidean().
New skew finder for full angle range, pixFindSkewOrthogonalRange().
For skew detection, now allow shear about image center as well as
about the UL corner.
New rotation reg tests: rotate1_reg.c and rotate2_reg.c.
Better serialization format for boxaa; introduce new version numbers
for boxaa, pixa, and boxa, as required.
Proper init in boxGetGeometry(), boxaGetBoxGeometry(), and the
accessors in sel1.c and kernel.c.
Improved Numa functions in numafunc1.c and numafunc2.c; in
particular, numaMakeHistogramAuto() and numaGetStatsUsingHistogram().
With all histo generators, make sure the start and binsize params
are properly set and are used.
Interface change: Use these parameters implicitly in
numaHistogramGetRankFromVal() and numaHistogramGetValFromRank().
Interface change to ptaGetLinearLSF(): add 1 optional parameter.
In several pixaDisplay*() functions, handle colormaps properly.
pixafunc.c split to pixafunc1.c and pixafunc2.c.
New connected component selections and options in pixaSort.
Patch from Tony Dovgal for reading tiff rgba files.
Added new logical operation options for numas.
New pixConvertRGBToGrayMinMax() that chooses min or max of 3 components.
Computation of pixelwise aligned stats between multiple images
of the same size (e.g., video), in pix4.c.
Very fast binsort implemented for boxa and pixa.
Cleanup and rename stack, queue, heap and ptra functions:
all structs and typedefs start with "L_"
all functions start with "l"
Sel creation for crosses and T junctions.
New thresholding operations to binary; split out from adaptmap.c
into binarize.c.
Implementation of sauvola binarization, including use of pixtiling.
Added composite parallel union and intersection morphological operations.
Small changes to scaling and rotation to improve accuracy; only
visible on very tiny, symmetric images.
Implemented DPix (double precision data); useful for the mean
square accumulator for sauvola binarization.
New fast hybrid grayscale seedfill, in addition to the interative
version (contributed by Ankur Jain).
New or improved regression tests:
rotate1_reg, rotate2_reg, shear_reg, numa_reg, skew_reg,
ptra1_reg, ptra2_reg, paint_reg, smallpix_reg, pta_reg,
pixmem_reg, binarize_reg, grayfill_reg.
1.60 19 Jan 09
Fixed bug in pixBlockconv(), introduced in 1.59, that causes
overflow when convolving with an image that has white (255)
at the edges. [quickly found by Dave Bryan]
Include function to display freetype fonts in a pix.
The files freetype.c and freetype.h are in the distribution, but are not
yet linked into the library. This is contributed by Tony Dovgal,
and this version works only for MSVC.
Found that the problems with binary compression in giflib are fixed
with giflib 4.1.6.
1.59 11 Jan 09
Lots of changes since 1.58.
New files: affinecompose.c, ptra.c, warper.c, watershed.{h,c}.
Split: boxfunc.c --> (boxfunc1.c, boxfunc2.c, boxfunc3.c)
Improved connected component filtering, with logical functions
applied to indicator arrays (pix4.c, pixafunc.c, numafunc1.c).
Function to determine if an image can be quantized nicely with
only a few colors (colorcontent.c, pixconv.c).
New gray seed-filling functions (seedfill.c, seedfilllow.c).
Fixed bugs in tophats and hdome, due to misuse of pixSubtractGray()
(morphapp.c).
New function for improving contrast (adaptmap.c)
Watershed transform (still slightly buggy) (watershed.c,h).
Fast random access into a pix using line pointers (pix1.c, arrayaccess.*)
Conversions of colormaps from gray to color and v.v. (colormap.c)
Seedfill function that applies an upper limit to the fill
distance (seedfill.c)
New function for warping images with random harmonic distortion
(with help from Tony Dovgal).
New generic ptr array utility: all O(1) functions of a stack plus
random replace, insert and delete (ptra.c).
Simple functions for colorizing a grayscale image with an arbitrary
color (pixconv.c, colormap.c)
Flexible affine transforms (translation, scale, rotation) on pta
and boxa (affinecompose.c).
Clipping of foreground (both exact and approximate) starting from
within a rectangular region of the image (pix4.c)
Blending a colored rectangle over an image (pix2.c, boxfunc3.c)
Generation of rectangle covering of mask components (boxfunc3.c).
Block convolution using tiles (for very large images) (convolve.c)
New or improved regression tests in prog:
locminmax_reg, lowaccess_reg, grayfill_reg, adaptnorm_reg,
xformbox_reg, warper_reg, cmapquant_reg, compfilter_reg,
splitcomp_reg, affine_reg, bilinear_reg, projective_reg
Acknowledgments:
(1) Big thanks to Tony Dovgal for helping with the warping
(e.g. for captcha). Tony also provided an implementation that
allows rendering truetype fonts into a Pix on windows.
This is not yet incorporated, because it opens a huge
"can of worms," which is OK if you're going fishing but
maybe not if you're trying to support leptonica on many platforms.
TBD.
(2) David Shao provided a libtools build system that includes
building the prog directory! I believe this will work, but it
is is not yet included because of problems I continue to have
with macros in version 2.61 of gnu libtools.
(3) Steve Rogers is working on a MSVC build for the prog directory.
I hope to have this available for 1.60.
1.58 27 Sept 08
Added serialization for numaa.
New octree quantizer pixOctreeQuantByPopulation(), that uses a
mixture of level2 and level4 octcubes. Renamed many functions
in colorquant1.c, and arranged/documented them more carefully.
Revised documentation in leptonica.org/papers/colorquant.pdf.
Simplified customization for I/O libraries and fmemopen() in environ.h.
Fixed bugs in colormap.c, viewfiles.c, pixarith.c.
Verified Adam Langley's jbig2enc (encoding jbig2 and generating pdf from
these encoded files) works properly with the current version -- see
Section 24 of README.html for usage and build hints.
New separable convolution; let pixConvolve() take 8, 16 and 32 bpp input.
New floating pt pix (FPix) utility, which allows convolution and
arithmetic operations on FPix; also interconversion to Pix.
Ability to read headers on multipage tiff.
More robust updown text detection in flipdetect.c.
Use of sharpening to improve scaling when the scale factor is near 1.0.
See prog/fpix_reg.c for regression test and usage.
See prog/blend_reg.c for blending regression test, with new functions.
1.57 13 Jul 08
New Debian distribution for 1.57 (thanks to Jeff Breidenbach).
Improved the Otsu-type approach for finding a binarization threshold,
by choosing the min in the histogram subject to constraints
(numafunc2.c, adaptmap.c)
New function pixSeedspread() in seedfill.c, similar to a voronoi tiling,
that is used for adaptive thresholding in pixThresholdSpreadNorm().
In the process, fixed a small bug in pixDistanceFunction().
(The approach was suggested by Ray Smith, and uses the fast
Vincent distance function method to expand each seed.)
Generalized the functions in kernel.c to use float weights
for general convolution (Version 2 for kernel), and added
gaussian kernel generation.
Put all jpeg header functions into jpegio.c, where they belong.
Fixed bugs in pixaInsertPix() and pixaRemovePix().
Added read/write serialization for Numaa.
New functions for comparing two images using bounding boxes (classapp.c).
1.56 12 May 08
Added several new 1d barcode decoders. The functional interface
is still in flux.
Autoconf! To get this working, it was necessary to: determine and
set the endian flag; select which libraries are to be linked;
determine if stream-based memory I/O is enabled.
This required a major cleanup of the include files, minimizing
dependencies on external library header files, and getting everything
to work with both autoconf (HAVE_CONFIG_H) and the old
customized makefile. Customization is now all in environ.h.
pixSaveTiled(): a new way to display tiled images.
pixtiling.c: interface for splitting an image into a set of
overlapping tiles, using mirrored borders for tiles touching the
image boundary.
pixBlendHardLight(): new blending mode with nice visual effects.
pixColorFraction(): determines extent of color in image
Both octree and median-cut color quantization check first if
image is essentially grayscale; improvements to both algorithms.
box*TransformOrdered(): general sequence of linear transforms.
colorquant_reg.c, xformbox_reg.c, hardlight_reg.c: new regr tests.
1.55 16 Mar 08
New functions for combining two images arbitrarily through a mask,
including mirrored tiling (pix3.c)
Modify pixSetMasked*() to work on all images (pix3.c)
New functions for extracting masked regions such as pixClipMasked()
(pix3.c) and pixMaskConnComp() and pixMaskBoxa() (boxfunc.c).
New functions to separate fg from bg (pix3.c), one of which is supported
by numaSplitDistribution (numafunc.c).
Modify sobel edge detector to take another parameter (edge.c)
Support for 4 bpp cmyk color space in jpeg (jpegio.c)
Modified median cut color quantization (colorquant2.c)
Renamed colorquant.c (for octree quant) --> colorquant1.c.
Absorbed conncomp.h and colorquant.h into specific files that
depend on them (colorquant1.c, conncomp.c, pix.h)
General convolution with utility for building kernels
(convolve.c, kernel.c)
Initial implementation of 1D barcode reader. So far, we just have the
signal processing to locate barcodes on a page, deskew them, and
find the bar widths, along with decoders for two formats.
(readbarcode.*, prog/barcodetest.c)
Made the default to stub out read/write for non-tiff image formats
to memory; it doesn't work on Macs & they were complaining (*io.c)
Include MSVC project files for building leptonlib under
windows (leptonlib.*)
1.54 21 Jan 08
Histogram equalization (enhance.c).
New functions for pixaa: serialization (r/w), creation
from pixa, and a tiled/scaled display into a pixa (pixabasic.c,
pixafunc.c).
Read/write of tiff to memory (instead of a file, using
the TIFFClientOpen() callback interface), contributed by Adam
Langley (tiffio.c, testing in prog/ioformats_reg).
Improved image statistics functions, both over tiles and
through a mask over the entire image. Added standard deviation
and variance; enable statistics for rgb and colormapped images,
in addition to 8 bpp grayscale (pix3.c). New function to
extract rgb components from a colormapped image (pix2.c).
Fix pixWriteStringPS() to work with all depths and colormap (psio.c)
Enable all non-tiff formats to also write and read to/from memory (*io.c)
Added support for read/write to gif, contributed by Tony Dovgal
(gifio.c, gifiostub.c, imageio.h). See Makefile for instructions
on enabling this.
1.53 29 Dec 07
Add 4th arg to pixDistanceFunction() to specify b.c.,
and fixed output to 16 bpp grayscale pix. (seedfill*.c)
New un-normalized block grayscale convolution (convolve.c)
Fixed bug in getLogBase2(), so that pixMaxDynamicRange() works
properly. This is useful for displaying a 16 bpp pix as
8 bpp (pixarith.c). New function for getting rank val for
rgb over a region specified by a mask (pix3.c). New function
for extremem values of rgb colormap (colormap.c). New
function pixGlobalNormNoSatRGB(), a variant of pixGlobalNormRGB()
that prevents saturation for any component above a specified
rank value (adaptmap.c). Added mechanism for memory
management of pix (pix1.c). Added selective morphology by
region given by a mask (morphapp.c). Fixed prototype extracdtion
to work properly with function prototypes as args; released
version 1.2 of xtractprotos (parseprotos.c, xtractprotos.c).
Add a boxa field for pixaa, along with serialization (pixabasic.c),
and modified display of pixaa to include this (pixafunc.c).
Coalesced the version numbers for pixa, pixaa, boxa, and boxaa
serialization (pix.h).
New progs: modifyhuesat displays modified versions on a grid;
textlinemask shows simple methods for extracting textline masks.
1.52 25 Nov 07
Implemented Breuel's whitespace partitioning algorithm (partition.c).
Generalized pixColorMagnitude() to allow different methods
for computing the color amount of a pixel (colorcontent.c).
New methods for computing overlap of boxes (boxfunc.c).
New methods for painting (solid) and drawing (outline) of boxes,
replacing boxaDisplay() with pixDrawBoxa*() and pixPaintBoxa*()
(pix2.c, boxfunc.c).
Ray Smith fixed bug in the distance function (seedfilllow.c).
For pixConvertTo1() and pixConvertTo8(), treat input pixs as a
const and never return a clone or altered cmap (pixconv.c).
Make pixGlobalNormalRGB() crash-proof (adaptmap.c).
Tony Dovgal added ability to read jpeg comment (jpegio.c).
1.51 21 Oct 07
Improved histogramming of gray and color images (pix3.c)
Histogram statistics (numafunc.c). Better handling of tiff
formats, testing rle and packbits output and improving
level 2 postscript conversion efficiency (readfile.c, psio.c).
Test program for r/w and display of Sels (prog/seliotest.c).
Use endiantest to determine automatically which flags to set
when compiling for big- or little-endians (endiantest.c)
Compute a color magnitude for each rgb pixel (colorcontent.c).
Allow separate modification of hue and saturation (enhance.c).
Global transform of color image for arbitrary white point (adaptmap.c).
1.50 07 Oct 07
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NOTE CAREFULLY: The image format enum in imageio.h has
changed. This is an ABI change, and it requires
recompilation of the library.
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Suggestions by David Bryan again resulted in several changes,
including improvements to the dwa generating functions and interfaces.
Major improvements for dwa code generation, including an
optional filename for the output code, adding function prototypes
to the code so it can easily be linked outside the library.
Addition of 2-way composable dwa functions for bricks, with
code addition to the library, and a new interpreter for dwa
composable brick sequences (fmorphauto.c, fhmtauto.c,
morphtemplate1.c, hmttemplate1.c, morphdwa.c, dwacomb*.2.c, morphseq.c)
Exhaustively tested in six programs (prog/binmorph*_reg,
prog/dwamorph*_reg).
New input modes for Sels, from both color bitmap editors
and a simple file format (sel1.c).
Better Sel generation functions in sel2.c, including combs for
composable brick operations and linear bricks for comparison.
Removed unnecessary copies for more efficient border add'n & removal.
Added RLE basline enc/dec for tiff.
Binary morphology documentation on the web page updated for these
changes/additions.
William Rucklidge unrolled inner loops and added LUTs to
speed up several more functions, including correlation
(correlscore.c), centroid calculation (morphapp.c),
2x linear interp grayscale scanning (scalelow.c),
thresholding to binary (grayquantlow.c), and removal
of colormaps to gray (pixconv.c).
1.49 23 Sep 07
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NOTE CAREFULLY: The image format enum in imageio.h has
changed. This is an ABI change, and it requires
recompilation of the library.
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Suggestions by David Bryan resulted in several changes.
pixUnpackBinary() unpacks to all depths.
Can now write and read tiff in LZW and ZIP (gzip) formats.
These, like uncompressed tiff, work on all bit depths.
Also enabled pnm 16 bpp r/w, both non-ascii and ascii.
ioFormatTest() now has better coverage and clarity; this is
used in prog/ioformats_reg.c.
Rewrite of morphautogen code to implement opening and closing atomically.
Cleaner interaction with new text templates (fmorphauto.c,
fhmtauto.c, sarray.c, *template*.txt,).
More regression testing (e.g., binmorph1_reg.c, binmorph3_reg.c).
1.48 30 Aug 07
William Rucklidge sped up pixCorrelationScore() by in-lining
all bit operations (jbclass.c).
Generalized rank filtering from 8 bpp to color (rank.c).
Fixed many functions that take a dest pix so that they don't fail if
the dimensions or depth are not consistent with the src pix.
The underlying change for this is to pixCopy() (pix1.c).
Improved display of Sel as a pix; added selaDisplayInPix() to
display all Sels in a Sela, orthogonal rotations of Sels (sel1.c).
New functions for thinning and thickening while preserving connectivity
and avoiding both free end erosion and dendritic cruft (ccthin.c,
prog/ccthin1_reg.c, prog/ccthin2_reg.c).
New function pixaDisplayTiledInRows() for compactly tiling pix
in a pixa, plus documentation of different existing methods. (pixafunc.c)
1.47 22 Jul 07
New brick rank order filter (rank.c, prog/ranktest.c, prog/rank_reg.c).
Use mirror reflection b.c. to avoid special processing at
boundaries (pix2.c). Simple sobel edge detector (edge.c).
Utility for assempling level 2 compressed images in PostScript
(psio.c, prog/convertfilestops.c). Enable read/write of 16 bpp,
grayscale tiff (tiffio.c, pix2.c).
New function for finding the number of c.c., which is a bit
faster than finding the b.b. or the component images (conncomp.c)
New functions for finding local extrema in grayscale image (seedfill.c)
1.46 28 Jun 07
Added interpreted mode for color morphology (morphseq.c).
In functions, make effort to consistently do early initialization
of ptrs to objects returned on the heap. This is to try to
avoid letting functions return uninitialized objects, even if
the return early because of bad input.
Split pixa.c into 2 files; revised the component filtering
in both pixafunc.c and boxfunc.c. Added component filtering
for "thin" components.
Added subsampling functions for numa and pta.
Word segmentation now works at both full and half resolution.
Better methods for displaying and tiling (for debugging),
using pixDisplayWrite(), pixaReadFiles() and pixaDisplayTiledAndScaled().
1.45 27 May 07
Further improvements of orientation and mirror flip detection
(flipdetect.c). Added 2x rank downscaling and general integer
replicative expansion (scale.c). Simplified interface for
averaging, and included tiled averaging, which is yet another
integer reduction scaling function (pix3.c).
1.44 1 May 07
Split pix2.c into (pix2.c, pix3.c), with basic housekeeping
functions (e.g., ops on borders, padding) in pix2.c.
Split numarray.c into (numabasic.c, numafunc.c), with
constructors and accessors in numabasic.c. Added a number
of histogram, rank value and interpolation functions to numafunc.c.
Add rms and rank difference comparison functions (compare.c).
Separated orientation and mirror flip detection; fixed the latter
(flipdetect.c).
1.43 24 Mar 07
New and fixed functions for handling word boxes (classapp.c)
More consistent use of L_* flags (e.g., sarray.h, morph.h)
Morphology on color images (gray ops on each component) (colormorph.c)
New methods for generating sels; we now have five methods in
sel1.c and 3 others in selgen.c. Also a function that
displays Sels as an image, for use in documentation (sel1.c)
New high-level converters, such as pixConvertTo8(), pixConvertTo32(),
pixConvertLossless() (pixconv.c)
Identify regression tests, and rename them as prog/*_reg.c.
Complete revision of plotting package (gplot.c)
New functions for comparing pix (compare.c)
New morph application functions, such as the ability to run a
morph sequence separately on selected c.c. in an image, and
a fast, quasi-tophat function (morphapp.c)
Cleanup and new interfaces to border representations of c.c. (ccbord.c)
Page segmentation application (pageseg.c)
Better serialization with version control for all major structs.
Morphological brick operations with 2-way composite sels (morph.c)
1.42 26 Dec 06
New sorting functions, including 2-d sorting, for boxa and pixa,
and functions that sort by index (e.g., pixa --> pixa and
for 2d, pixa --> pixaa; ditto for boxa).
New accessors for pix dimensions. A new strtokSafe() to
substitute for strtok_r (utils.c).
Page flip detection, using both rasterop and dwa morphology
(flipdetect.c), with dwa generation (fliphmtgen.c) and testing
(prog/fliptest.c).
Increased basic sels from 42 to 52 (sel2.c).
Better high-level interfaces for binary morphology with
brick (separable) sels, both for rasterop (morph.c) and for
dwa (morphdwa.c); fully tested for both asymmetric and
symmetric b.c. (prog/morphtest3.c). Faster area mapping
reduction for power-of-2 scaling.
1.41 5 Nov 06
Simplified morph enums, removing all unused ones (morph.h).
Added new high-level interfaces for adaptive mapping (adaptmap.c).
New method to extract color content of images (colorcontent.c).
New method to generate sels from text strings, and to identify
roman text that is not properly oriented (thanks to Adam Langley).
Fast grayscale min/max (rank) scale reduction by integer factors.
New accessors for box and sel, that should be used when possible.
Thresholding grayscale mask by bandpass (grayquant.c).
Use of strtok_r() for thread safety.
1.40 15 Oct 06
Fixed xtractprotos for cygwin. Minor fixes and improved documentation
(baseline.c, conncomp.c, pix2.c, morphseq.c, pts.c, numarray.c,
utils.c, skew.c). Add ability to quantize an rgb image to a
specified colormap (colorquant.c); tested in prog/cmapquanttest.c.
Modifications to allow conditional compilation on MS VC++,
and to allow I/O calls to be stubbed out (new files: *iostub.c,
zlibmemstub.c, pstdint.h, arrayaccess.h.ms60)
1.39 31 Aug 06
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NOTE CAREFULLY: There has been an interface change to make
affine, bilinear and projective transforms more general.
The implementation has been changed to allow them to handle
all image types and to make them faster (esp. with both sampled
and interpolated mapping on color images).
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Added prog/Makefile.mingw to build executables. This is still
in a relatively raw state. It is necessary to download
gnuwin32 packages for 4 libraries (jpeg, png, zlib, tiff)
to link with leptonlib and the main, and I still have not
been able to build static executables (they require jpeg2b.dll, etc.).
1.38 8 Aug 06
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NOTE CAREFULLY: There has been an interface change to both
simplify and generalize the grayscale morphology operations:
pixErodeGray(), pixDilateGray(), pixOpenGray(),
pixCloseGray(), pixTophat() and pixMorphGradient().
The prototypes are not changed; old code will compile, but
it will be wrong! The old interface had a size and a type
(horizontal, vertical, square). The new interface takes
horizontal and vertical Sel dimensions.
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
For cross-compilation to make windows programs, you can use
src/Makefile.mingw to make a windows version of the library.
6x scale-to-gray function donated by Alberto Accomazzi.
Interpreter added for sequence of grayscale morphological
operations, including the tophat (morphseq.c).
Pixacc container added to simplify the interface
for accumulator arithmetic using Pix.
Removed fmorph.c and fmorphlow.c from the library. These are
very limited and were deprecated in favor of fmorphauto(), which
autogens the code from (nearly) any Sel.
Fixed some of the gray morphology operations, which had errors
on the boundary. All gray morph ops should now be rigorously
OK (graymorph.c). For testing of graymorph dualities, the
the graymorph interpreter, etc., see prog/morphgraytest.c.
1.37 10 Jul 06
[After v.36 was released, Jeff Breidenbach built a Debian
distribution of Leptonica based on v.36, and you can now get Leptonica
as a Debian package. Use "apt-cache search leptonica" to see
what is available.] The libraries are now combined into a single
library (liblept.a, liblept.so) and the function prototypes are
also in a single file (leptprotos.h). cextract was found not
to work on recent versions of linux that support 64 bit data types,
and it is no longer distributed with leptonica. Instead, I wrote
a prototype extractor in leptonica (xtractprotos). When you
'make allprotos', it now uses this program. The shared libraries
now have major and minor numbers corresponding to the version.
1.36 17 Jun 06
Line graphics generation (graphics.c) reorganized; separated out pta
generation from rendering. Can now render with alpha blending.
Examples of use are given in prog/graphicstest.c.
Sort functions for basic geometrical objects now have the option
of returning a numa giving the sort order on the original array.
The pixa sort can sort with either clones or copies of the pix.
1.35 21 May 06
The efficiency of the multipage jbig unsupervised classifier is
significantly improved due to a NumaHash struture implemented
by Adam Langley. Functions for computing runlength in 1 bpp
images have been added.
1.34 7 May 06
Completely rewrote the jbig unsupervised classifier.
It now works on multiple pages, and is more accurate in performing
visually lossless substitutions. You can classify by connected
components, characters, or words. The old data structures
and interfaces have been removed. New unpackers from 1 to 2 and
1 to 4 bpp, with and without colormaps in the dest.
1.33 18 Mar 06
Generalized color snap to have different src and target colors,
and to include colormaps (blend.c). Distribute into root directory
that specifies the version number (e.g., 1.33). Add color
space conversion between rgb and hsv. Re-bundle thresholding
code from (binarize*.c, dibitize*.c) to grayquant*.c.
pixThreshold8() now also quantizes 8 bpp --> 8 bpp.
High-level pixRotate() that optionally expands image sufficiently
so that no pixels are lost in any sequence of rotations (rotate.c).
Generalize shear to specify color of pixels brought in, including
for in-place operation (shear.c, rotateshear.c). Faster version of
color rotation by area mapping, both about center and about UL corner.
You can now use the standard color rotator (pixRotateAM) and get
nearly the same speed as with the "Fast" one.
1.32 4 Feb 06
Ability to specify a sequence of binary morphological
(& binary reduction/expansion) operations in a single
function (morphseq.c). Fast downscaling combined with conversion
from rbg to gray and to binary (scale.c). Utility for
segmenting images by color (colorseg.c).
1.31 7 Jan 06
Remove more complicated functions that threshold to 2 bpp,
retaining the simplest interface. Retest all thresholding and
dithering. Add "ascii" write of PNM. Improve graphics writing
of lines; generalize to colormaps. New colorization functions
(paintcmap.c, blend.c).
1.30 22 Dec 05
Remove most instances of fprintf(stderr, ...), except within
DEBUG or encapsulated in error, warning or info macros.
As a result, there is no output to stderr if NO_CONSOLE_IO is defined.
Adaptive mapping to make bg uniform (adaptmap.c). A few bug fixes.
New PostScript output functions for embedding PS files
(prog/converttops). Generalized some image enhancement functions.
New functions for generating hit-miss sels.
1.29 12 Nov 05
More flexible blending of two images, with and without colormaps
(see blend.c). Painting colormapped images through masks, etc
(see paintcmap.c). More flexible interface for gamma and
contrast enhancement (see enhance.c).
1.28 8 Oct 05
Removed all pix colormaps for 1 bpp. Allow programmatic resetting
of binary morphology boundary conditions. Added (yet) another
simple octcube color quantizer. New colormap operations.
1.27 24 Sep 05
Renamed many of the enums and typedefs to avoid namespace
collisions. This includes structs and typedefs for BMP.
Interface change to pixClipRectangle(); apologies to everyone
whose code is broken by these changes -- I hope it's worth it.
Removed colormap.h; simplified all colormap usage, hiding details
from all but a few colormap functions. Am now saving file format
in the pix when an image is read, and can by default write
out in this format. Resolution info added for jpeg and png.
Added L_INFO* macros and l_info* fctns for printing
(e.g., debugging) info. Suggestions and code kindly
supplied by Dave Bryan, who helped solve compatibility issues
with MINGW32 (e.g., in timing and directory functions).
Added some blending and linear TRC functions.
Generalized pixEqual() to include all cases with and without
colormaps. New regression tests in prog: ioformats, equaltest.
1.26 24 Jul 05
Generalized affine pointwise to do interpolation as well as
sampling. For both projective and bilinear transforms,
implemented using both sampling and interpolation.
Added function to remove keystoning by computing the necessary
projective transform and doing it. Also find baselines in text images.
Added downscaling using accurate area-mapping over subpixels.
1.25 25 Jun 05
Better endian conversion fctns for 2 and 4 byte words.
Remove colormaps before converting by thresholds.
Added functions to read header parameters for png and tiff.
1.24 5 Jun 05
Added image splitting to allow printing in tiles (as several pages).
Added new octree quantization function to generate 4 and 8 bpp
colormapped output (not dithered). Fixed bmp resolution.
Added new flag for colormap removal (using dest depth based on
src colormap). Added I/O tests (prog/ioformats.c)
1.23 10 Apr 05
Added thresholding from 8 bpp to 2 and 4 bpp, allowing specification
of both the number of output levels and whether or not a colormap
is made.
1.22 27 Mar 05
Add pointer queue facility. To demonstrate it, you can now
generate a binary maze using a cellular automaton and find
the shortest path between two points in the maze. Add heap
of pointers (keyed on the first field), which is used to
implement a priority queue. This is applied to search for
a "least cost" path on a grayscale image (a generalization
of a binary maze).
1.21 28 Feb 05
Read/write of colormaps to file. For gplot, add a new
latex output terminal. Bring ptrs into 21st century by
including stdint.h, and using uintptr_t for the ptr address
arithmetic in arrayaccess.*. This seems to be OK back to
RH 7.0, but if you run into trouble with an earlier
C compiler, let me know. Also, use enums for global
constants whenever possible, and qualify named constants
(e.g., ADD --> ARITH_ADD, HORIZ --> MORPH_HORIZ) to avoid
possible interactions with other libraries.
1.20 31 Jan 05
Speed up of tiffio and pngio with byte swap generating new pix.
In textops.c, ability to split string into paragraphs,
in preparation for more general typesetting.
Automatic hit-miss Sel generation for pattern matching.
Fast downscaling using a lowpass filter and subsampling.
Generalization of several grayscale and color operations
to work on colormapped images. Improved scale-to-gray and
scaling reduction operations to be antialiased for best results.
1.19 30 Nov 04
Additions to fileIO: (1) new jpeg reading options, such as
returning warnings and scaled raster; (2) ability to write
custom tiff flags. Better tiling functions.
Edge extraction, both with grayscale morphology
and clipped convolution filters. More general painting
through a binary mask: pixSetMaskedGeneral().
Unpacking from binary to 8, 16 and 32 bpp. Thresholding
and dithering from 8 bpp to 2 bpp ("dibitization"). New bitmap
font facility, using a single rendered font in a variety of
sizes: allows painting the text on an image (binary, gray, RGB).
(People have asked for the ability to write text on images).
1.18 25 Aug 04
Changed typedefs of built-in types to avoid possible conflicts.
Cleaned up and tested all programs in the prog directory.
Simplified and fixed the pixSetMasked() and pixCombineMasked()
functions.
1.17 31 May 04
Implemented distance function for 16 bpp. We can now generate
out 16 bpp PNG. Simple programs for generating PS from a
directory of g4tiff or jpeg images. Changed implementation of
erosion to allow either asymmetric or symmetric boundary conditions.
The distinction is described on the binary morphology web page.
Allow read/write of multipage TIFF files. Implemented
read/write of PNM files.
1.16 31 Mar 04
New depth conversion functions, improved conversion to false color,
new contour rendering (onto 1 bpp or onto the src grayscale image),
new orthogonal rotations, better interface for doing arithmetic
on 2-d arrays using a pix, improved distance function.
1.15 31 Jan 04
Fast interpolated color rotation with 4x4 subpixels; has
nearly the accuracy of the slower method using 16x16 subpixels.
Demonstration of line removal from grayscale sketch in
prog/lineremoval.c. Conversion of grayscale to false color.
Fixed shear and rotation functions to handle angle = 0.0 properly.
Other small fixes and interface improvements.
1.14 30 Nov 03
Small implementation changes to list.c. Better sorting
routines for number arrays (numa), plus sorting for box
arrays (boxa) and pix arrays (pixa). PostScript wrapper
for jpeg. Better handling of colormaps, and a simple
function to convert an RGB pix with not more than 256
colors to the smallest colormapped pix. PS output wrappers
for JFIF JPEG and TIFF G4 files. Comments compatible
with doxygen for automatic documentation.
1.13 31 Oct 03
Cleaned up documentation in src. Made libraries and test programs
ANSI C++ compliant. Added special cases to rasterops for
alignment to word boundaries. Fixed pngio.c to work with
most recent libpng (1.2.5).
1.12 30 Jun 03
Implemented border chain representation from a binary image,
writes/reads a compressed version, and renders the original
image back from the borders. Also writes outline file out
in svg format. Number arrays (numa) and point arrays (pta)
are also extended to 2nd level arrays (numaa, ptaa).
Serialized I/O for boxa, pta, and pixa.
1.11 31 May 03
Implemented generic list handling, for doubly-linked
list cons cells and arbitrary objects.
1.10 14 Apr 03
Implemented simple image enhancements in gray and color:
gamma correction, contrast enhancement, unsharp masking.
Extended smoothing via block convolution to color.
Implemented auto-gen'd DWA version of hit-miss transform;
the code for generating these hmt routines is very similar to
that for DWA auto-gen'd erosion and dilation.
1.9 28 Feb 03
Implemented a safe, expandable byte queue. As an example of
its use, implemented memory-to-memory compression and decompression
using zlib. Generalized PS write to include RGB color.
Implemented a method to find image skew.
1.8 31 Jan 03
Implemented a simple 1-pass color quantization with dithering,
and improved the 2-pass octree color quantization.
Documented with an application page, that includes jbig2.
Added new general sampling operations and made a table
that summarizes the available scaling operations.
1.7 31 Dec 02
Added pixHtmlViewer(), a formatter that allows portable viewing of
a set of images (like a slide show) in a browser.
Implemented better octree color quantization, with variable
number of colors, pruning the octree for good color clusters,
and fast traversal for pixel assignment to colormap.
1.6 30 Nov 02
Generalized shear and shear rotation to arbitrary locations
about which the operation is performed. Implemented in-place
translation using pixRasteropIP(). Implemented arbitrary
affine transform of image two ways: pointwise and sequential.
Added binarization by error diffusion. Added simple color
quantization by octree.
1.5 31 Oct 02
Put jpeglib.h in local directory. This, along with the jmorecfg.h
file there prevents compiler warnings about redefined typedefs.
Compiled everything with g++ to make strictly ansi C compatible.
Added interface gplotFromFile() for simple file-based plotting with
gnuplot 3.7.2. Added functions to convert 2, 4 and 8 bpp
color-mapped (i.e., paletted) images to 24 bpp color or
8 bpp grayscale. Added several jbig2 application cores that
only require a simple wrapper to make into programs.
1.4 30 Sep 02
Added interface to gnuplot 3.7.2 and to x11 display of images.
Added new functions with arrays of images for use in applications
such as jbig2 encoders, along with a simple jbig2 implementation
using either hausdorff or correlation scoring. Added centroid
finder for images. For accessing image arrays from arrays of
image arrays, added a "new reference" (NEW_REF) flag, with a
ref count attached to the array. Added power-of-2 binary
expansion and reduction.
1.3 30 Jun 02
Extended connected components to 8. Added morphological
operations tophat and hdome, along with clipped arithmetic
operators on grayscale images. Fixed memory error in
rasteropGeneralLow() that was found using valgrind.
Tested most operations with valgrind for memory errors.
Replaced integer arrays with number arrays, to include floats.
Added arithmetic functions on grayscale images.
1.2 30 May 02
Added connected component utility, stack utility, pix arrays,
line drawing and seed filling. Binary reconstruction,
both morphological and raster-oriented, are now supported
for 4 and 8 connected fills. Added the distance function
on binary images, grayscale reconstruction, and grayscale
morphology using the Gil-Werman method.
1.1 30 Apr 02
Added orthogonal rotations, binary scaling, PS output,
binary reconstruction, integer arrays, structuring element
input/output.
1.0 25 Feb 02
Initial distribution, with rasterops, binary morphology (two
implementations: rasterops and dwa), affine transforms
(translation, shear, scaling, rotation), fast convolution,
and basic i/o (BMP, PNG and JPEG).
